Details
| Length | 500 |
| Thickness | 1.5 |
| Width | 245 |
| Backing Material | Standard Steel |
Material Specification
| Structure | S.A.E. 1010 steel backing strip with sintered bronze and PTFE layers |
|---|---|
| Max PV – Dry (N/mm² x m/s) | 1.8 |
| Max PV – Oiled (N/mm² x m/s) | 2.8 |
| Max Static load (N/mm²) | 250 |
| Max Dynamic load (N/mm²) | 140 |
| Max Sliding speed – Dry (m/s) | 2.5 |
| Max Sliding speed – With Oil (m/s) | 5 |
| Operating temperature (°C) | -200 to 280 |
| Thermal Conductivity (W/mk) | 42 |
| Coefficient of friction – Dry | 0.02 to 0.20 |
| Coefficient of friction – With Oil | 0.02 to 0.15 |
| Recommended shaft finish (Ra) | 0.04 max (N5) |
| Recommended shaft hardness (HB) | 200 min |
Tolerances & Fittings (Metric)
| Min | Max | Tolerance | |
|---|---|---|---|
| Overall Length | 500 | 503 | |
| Thickness Tolerance | 1.47 | 1.51 | |
| Width Tolerance | 245 | 255 |
Frequently Asked Questions
What is WMU PTFE strip used for?
WMU PTFE strip is a self-lubricated bearing material made from carbon steel with a sintered bronze layer filled with PTFE. It is used for industrial bearing and sliding applications where a PTFE-lined strip material is required.
What thicknesses are available?
WMU PTFE bearing strip is available in metric and imperial sizes from stock. The available thickness depends on the specific strip size and specification. Contact Bowman for details on the available options.
Can the strip be custom cut?
Yes. Bowman’s in-house machining service can produce non-standard sizes to suit specific customer requirements. This makes WMU bearings suitable for applications requiring dimensions beyond the standard range.
What are the load limits?
Load limits depend on the bearing dimensions, operating conditions, and specific application. For the appropriate WMU PTFE bearing specification for your application, contact Bowman for technical guidance.
How do I request a quote?
To request a quote, provide your required dimensions, quantity, and application details. Bowman is an industrial WMU bearing supplier US customers can contact for standard and custom requirements, including customers looking to buy WMU bearing bearings North America. For WMU bearings USA requirements, our team can provide further information on the appropriate solution.
